| MODEL | EL-FLN10 | EL-FLN20 | EL-FLN30 | EL-FLN50 | EL-FLN70 | EL-FLN100 | EL-FLN150 | EL-FLN200 | EL-FLN300 |
|---|---|---|---|---|---|---|---|---|---|
| Dimension | 103x71x27mm | 128x91x28mm | 160x110x28mm | 190x133x28mm | 239x166x28mm | 284x193x32mm | 339x231x32mm | 406x273x32mm | 508x318x36mm |
| LED Power | 10W | 20W | 30W | 50W | 70W | 100W | 150W | 200W | 300W |
| Chip Type | SMD3030 | ||||||||
| Lumen | 90-100LM/W | ||||||||
| CCT | 3000K/4000K/7000K | ||||||||
| CRI | Ra>80 | ||||||||
| Beam Angle | 120° | ||||||||
| LED Â Driver | DOB Solution | ||||||||
| Power Factor | PF>0.9 | ||||||||
| Surge protection | SPD>1.5-4kV | ||||||||
| Voltage | AC200-240V | ||||||||
| IP Grade | IP65 | ||||||||
| Material | Aluminum+High Tempered Glass | ||||||||
| Qty/Carton | 60 | 50 | 40 | 30 | 20 | 10 | 10 | 8 | 3 |
| Pack Size(cm) | 33x33x18.5 | 66.5x17x23 | 34.5x32.5x28 | 60x17x32.5 | 50x33x20.5 | 37x30x22.5 | 37x35x27.5 | 41.5x30x31 | 53x16.5x36 |
